Applications / Variable Speed Fan
PMSM with
Integrated Drive.
Performance redefined.
Discover the revolutionary advantages of Permanent Magnet Synchronous Motors (PMSM) equipped with an integrated drive system. Engineered to maximize reliability while drastically reducing maintenance and operational costs.
Advantages
Why choose Integrated PMSM?
Reliability
- The PMSM Motor with Integrated Drive adopts a film capacitor, and the life is several times that of electrolysis.
- The stator winding of PMSM motor is vacuum impregnated, which greatly improves the insulation performance and extends the life of the motor in a humid environment.
- The PMSM Motor with Integrated Drive has good cooling effect due to the airflow of fan.
- The speed regulation of the PMSM with Integrated Drive completely unaffected by the fluctuation of the power supply voltage, and the speed and air volume control are more precise.
- Support demagnetization detection function.
- High impulse voltage resistance for anti-surge and lightning protection 3.
- EMC compatibility meets EN IEC 61800-3.
Use & Maintenance
- The PMSM Motor with Integrated Drive adopts FOC control to realize constant speed control and ensure the air volume under high static pressure and low speed operation output.
- The setting parameters of the integrated drive are optimized and set for different models of motors in factory without on-site setting and commissioning.
- Plug & Play control cable from motor to controller Greatly reduces the workload and difficulty of installation, commissioning, use and maintenance.
- Available for Analog / Digital / EIN control modes.
- Manual and automatic mode switching and speed adjusting available for all fans in any control mode.
- Operating status indicator integrated with PMSM motor.
- In any control mode, the functions of individual warning output and fan force-starting by external input signal are available.
Cost
- The PMSM Motor with Integrated drive has built-in multiple protections without additional protection circuits, which simplifies the power supply system.
- The PMSM Motor with Integrated Drive doesn't need control circuit and control cabinet. It reduces the cost of installation and commissioning.
Applications / Variable Speed Fan
PMSM with
Integrated Drive.
Performance redefined.
Discover the revolutionary advantages of Permanent Magnet Synchronous Motors (PMSM) equipped with an integrated drive system. Engineered to maximize reliability while drastically reducing maintenance and operational costs.
Advantages
Why choose Integrated PMSM?
Reliability
- The PMSM Motor with Integrated Drive adopts a film capacitor, and the life is several times that of electrolysis.
- The stator winding of PMSM motor is vacuum impregnated, which greatly improves the insulation performance and extends the life of the motor in a humid environment.
- The PMSM Motor with Integrated Drive has good cooling effect due to the airflow of fan.
- The speed regulation of the PMSM with Integrated Drive completely unaffected by the fluctuation of the power supply voltage, and the speed and air volume control are more precise.
- Support demagnetization detection function.
- High impulse voltage resistance for anti-surge and lightning protection 3.
- EMC compatibility meets EN IEC 61800-3.
Use & Maintenance
- The PMSM Motor with Integrated Drive adopts FOC control to realize constant speed control and ensure the air volume under high static pressure and low speed operation output.
- The setting parameters of the integrated drive are optimized and set for different models of motors in factory without on-site setting and commissioning.
- Plug & Play control cable from motor to controller Greatly reduces the workload and difficulty of installation, commissioning, use and maintenance.
- Available for Analog / Digital / EIN control modes.
- Manual and automatic mode switching and speed adjusting available for all fans in any control mode.
- Operating status indicator integrated with PMSM motor.
- In any control mode, the functions of individual warning output and fan force-starting by external input signal are available.
Cost
- The PMSM Motor with Integrated drive has built-in multiple protections without additional protection circuits, which simplifies the power supply system.
- The PMSM Motor with Integrated Drive doesn't need control circuit and control cabinet. It reduces the cost of installation and commissioning.
